Model | Bağlantı Ölçüleri | A | B | C | D | E | F | H | H1 | |
DNA | DNM | (mm) | ||||||||
COE1-MSV406 M | 11/4" | 1" | 350 | 300 | 86,5 | 127,5 | 174 | 255,3 | 813 | 640 |
COE1-MSV408 M | 11/4" | 1" | 350 | 300 | 86,5 | 127,5 | 174 | 255,3 | 842 | 669 |
COE1-MSV408 T | 11/4" | 1" | 350 | 300 | 86,5 | 127,5 | 174 | 255,3 | 842 | 669 |
COE1-MSV410 T | 11/4" | 1" | 350 | 300 | 86,5 | 127,5 | 174 | 255,3 | 900 | 727 |
Model | Kolay Seçim | Nominal Güç-P2 | Nominal Akım (A) | Pompa Adedi | Ürün Kodu | |
(kW) | (HP) | |||||
COE1-MSV 406 M | 6 Kat - 29 Daire | 1x1,85 | 1x2,5 | 1x10 | 1 | 2851897 |
COE1-MSV 408 M | 9 Kat - 29 Daire | 1x2,2 | 1x3 | 1x12 | 1 | 2851903 |
COE1-MSV 408 T | 9 Kat - 29 Daire | 1x2,2 | 1x3 | 1x5,3 | 1 | 2855411 |
COE1-MSV 410 T | 14 Kat - 29 Daire | 1x3 | 1x4 | 1x6,6 | 1 | 2851904 |
COE2-MSV 406 M | 6 Kat - 29 Daire | 2x1,85 | 2x2,5 | 2x10 | 2 | 2850809 |
COE2-MSV 408 M | 9 Kat - 29 Daire | 2x2,2 | 2x3 | 2x12 | 2 | 2850810 |
COE2-MSV 408 T | 9 Kat - 29 Daire | 2x2,2 | 2x3 | 2x5,3 | 2 | 2855412 |
COE2-MSV 410 T | 14 Kat - 29 Daire | 2x3 | 2x4 | 2x6,6 | 2 | 2850811 |
